PCE Force gauge PCE-DFG 500 X
Sku: T-1515355
€619.37 (excl. legal VAT, excl. Shipping)
€824.92 MSRP
In stock,ready for shipping within 24h
Piece
doneMade in Germany
Measuring range: 0 ... 500 N
Measuring rate: 1 ... 7,200 Hz
Accuracy: ±0.05 % FS
Graphic display
USB-C interface
PC software
32 GB memory for 30 million measuring points
Measuring cells easily exchangeable
Various alarm modes
Bar chart for displaying the measured value in the measuring range
Calibration reminder
Measuring rate: 1 ... 7,200 Hz
Accuracy: ±0.05 % FS
Graphic display
USB-C interface
PC software
32 GB memory for 30 million measuring points
Measuring cells easily exchangeable
Various alarm modes
Bar chart for displaying the measured value in the measuring range
Calibration reminder
Content:
1 Piece
Shipping:
€167.98 Versandservice to United Kingdom
Lieferung:
Provider:
Sales and delivery by ToolTeam Köln
Payment methods:
Returns:
Security:
Product data
Manufacturer:
PCE Deutschland GmbH
Condition:
NEW
Sku:
T-1515355
SKU manufacturer:
PCE-DFG 500 X
GTIN Code (EAN):
4250348734891
Weight:
1,50 Kg
All information relating to products from PCE Deutschland GmbH. Technical and optical modifications of the manufacturer and errors reserved.
This page has been machine-translated, the original german version can be found here, please also note the Translation Disclaimer.
Product description
Both tensile and compressive forces can be measured with high accuracy using the force gauge. Tensile and compressive forces are frequently measured in test laboratories. For example, to determine the yield point, the tear-off force or the force required to actuate buttons or switches. The force gauge has an internal measuring cell and can measure forces of up to 500 N. Various eyelets or hooks with an M6 thread can be attached to the measuring cells. It is also possible to attach your own devices to the measuring cell using these threads.
The internal memory of 32 GB offers space for 30 million measuring points. This allows measurement logs to be created, saved and exported. The force gauge has a USB-C interface that can be used to read the measurement data into the PC software. The force tester is equipped with a graphic LCD that displays the measured values both numerically and graphically. In addition, a bar chart shows the measured value in the selected measuring range.
Various force test stands are available for adapting the force gauge.
Force
Measuring range 0 ... 500 N
Resolution 0.1 N
Accuracy ±0.05 % FS
General technical data
Unit(s) kPa, kg, g, ft, N, lb, t, kN, Pa, Nm, Ncm
Display type LCD with illumination
Display size 2.8 inch
Measurement rate adjustable 1 ... 7200 Hz
Memory medium Internal memory
Memory capacity 32 GB
Memory interval from 1 Hz
Memory interval up to 7200 Hz
Interface USB-C
Operating time 13 h
Automatic switch-off from ... to 1 ... 15 min.
Automatic switch-off can be deactivated Yes
Alarm visual, audible
Alarm modes Inside, Outside, Crack, Switch off
Menu language Turkish, English (US), Polish, Spanish, German, Chinese, Russian, Japanese, French, Danish, Italian, Dutch, Portuguese
Protection class (device) IP52
Power supply USB 5 V DC, 500 mA
Capacity 2500 mAh
Operating conditions -20 . .. 65 °C , 10 ... 95 % r. h.Storage conditions -20 ... 65 °C , 10 ... 95 % r. H.Dimensions ( L x W x H ) 165 x 85 x 32 mmWeight 255 g
1 x force gauge PCE-DFG 500 X
1 x adapter set
1 x case
1 x USB-C cable
1 x PC software
1 x operating instructions
The internal memory of 32 GB offers space for 30 million measuring points. This allows measurement logs to be created, saved and exported. The force gauge has a USB-C interface that can be used to read the measurement data into the PC software. The force tester is equipped with a graphic LCD that displays the measured values both numerically and graphically. In addition, a bar chart shows the measured value in the selected measuring range.
Various force test stands are available for adapting the force gauge.
Force
Measuring range 0 ... 500 N
Resolution 0.1 N
Accuracy ±0.05 % FS
General technical data
Unit(s) kPa, kg, g, ft, N, lb, t, kN, Pa, Nm, Ncm
Display type LCD with illumination
Display size 2.8 inch
Measurement rate adjustable 1 ... 7200 Hz
Memory medium Internal memory
Memory capacity 32 GB
Memory interval from 1 Hz
Memory interval up to 7200 Hz
Interface USB-C
Operating time 13 h
Automatic switch-off from ... to 1 ... 15 min.
Automatic switch-off can be deactivated Yes
Alarm visual, audible
Alarm modes Inside, Outside, Crack, Switch off
Menu language Turkish, English (US), Polish, Spanish, German, Chinese, Russian, Japanese, French, Danish, Italian, Dutch, Portuguese
Protection class (device) IP52
Power supply USB 5 V DC, 500 mA
Capacity 2500 mAh
Operating conditions -20 . .. 65 °C , 10 ... 95 % r. h.Storage conditions -20 ... 65 °C , 10 ... 95 % r. H.Dimensions ( L x W x H ) 165 x 85 x 32 mmWeight 255 g
1 x force gauge PCE-DFG 500 X
1 x adapter set
1 x case
1 x USB-C cable
1 x PC software
1 x operating instructions
