AMF 6151L-K10 built-in clamping module, flange version 424101
Sku: T-1509957
Discontinued item
Product variants
| Sku: | Name: | SKU manufacturer: | ||
|---|---|---|---|---|
|
T-1509958 | 6151L-K20 built-in clamping module, flange version | 423988 | |
|
T-1509959 | 6151L-K40 built-in clamping module, flange version | 424168 |
doneSize: KP10
doneM (mm): M5
doneM (mm): M5
doneR (mm): G1/8
doneT [mm]: 5,9
doneT [mm]: 5,9
Product data
Manufacturer:
AMF - Andreas Maier GmbH & Co.KG Schloss- u. Werkzeugfabrik
Condition:
NEW
Sku:
T-1509957
SKU manufacturer:
424101
GTIN Code (EAN):
4020772424107
Weight:
1,35 Kg
All information relating to products from AMF - Andreas Maier GmbH & Co.KG Schloss- u. Werkzeugfabrik. Technical and optical modifications of the manufacturer and errors reserved.
This page has been machine-translated, the original german version can be found here, please also note the Translation Disclaimer.
Product description
Built-in clamping module, flange version
open pneumatically.
Opening operating pressure: min. 8 bar - max. 12 bar.
Retightening operating pressure (turbo): min. 5 bar - max. 6 bar.
Cover and piston hardened.
Repeatability < 0.005 mm.
open pneumatically.
Opening operating pressure: min. 8 bar - max. 12 bar.
Retightening operating pressure (turbo): min. 5 bar - max. 6 bar.
Cover and piston hardened.
Repeatability < 0.005 mm.
Additional information
Size:
KP10
M (mm):
M5
R (mm):
G1/8
T [mm]:
5,9
K (mm):
9
Holding force (kN):
25kN
Ø D1:
67
Clamping force up to (kN):
8kN
Dimension DA:
100
ODN:
22
HA:
24
BEER:
90
Weight (kg):
1,35Kg
Related results
4020772424107
power clamps
clamping irons
clamping pads
straightening and support elements
clamping bolts and floating clamps
clamping screws
nuts and washers
clamping sets and accessories
pull-down clamps
positioning elements
stops and precision T-nuts
eccentric and centering clamps
AMF
424101
AMF - ANDREAS MAIER GmbH & Co. KG
Complete catalogs
The offer is aimed exclusively at business customers, companies, public institutions, tradesmen and freelancers. All prices in catalogues are exclusive of VAT, shipping costs and surcharges if applicable.
The manufacturer is exclusively responsible for the content, price and article details of the products and offers presented in the catalogues. Subject to technical and optical changes by the manufacturer and errors excepted.
The manufacturer is exclusively responsible for the content, price and article details of the products and offers presented in the catalogues. Subject to technical and optical changes by the manufacturer and errors excepted.
Matching catalog
