AMF 6830NIT-4 Horizontal clamp with black handle 558174
Sku: T-297802
€101.55 (excl. legal VAT, excl. Shipping)
€131.00 MSRP
In stock,ready for shipping within 48h
Piece
Product variants
| Sku: | Name: | SKU manufacturer: | ||
|---|---|---|---|---|
|
T-297798 | 6830NIT-0 Horizontal clamp with black handle | 558170 | |
|
T-297799 | 6830NIT-1 Horizontal clamp with black handle | 558171 | |
|
T-297800 | 6830NIT-2 Horizontal clamp with black handle | 558172 | |
|
T-297801 | 6830NIT-3 Horizontal clamp with black handle | 558173 |
doneWeight (g): 700g
doneC (mm): 41,0
doneC (mm): 41,0
doneE (mm): 63,0
doneF (mm): 27
doneF (mm): 27
AMF - ANDREAS MAIER GmbH & Co. KG 6830NIT-4 Horizontal clamp with black handle 558174
Content:
1 Piece
Shipping:
€41.93 Versandservice to United Kingdom
plus €10.00 stock transfer surcharge
Lieferung:
Provider:
Sales and delivery by ToolTeam Köln
Payment methods:
Returns:
Security:
Product data
Manufacturer:
AMF - Andreas Maier GmbH & Co.KG Schloss- u. Werkzeugfabrik
Condition:
NEW
Sku:
T-297802
SKU manufacturer:
558174
GTIN Code (EAN):
4020772019242
Weight:
0,68 Kg
All information relating to products from AMF - Andreas Maier GmbH & Co.KG Schloss- u. Werkzeugfabrik. Technical and optical modifications of the manufacturer and errors reserved.
This page has been machine-translated, the original german version can be found here, please also note the Translation Disclaimer.
Product description
Horizontal clamp with black handle with open holding arm and horizontal base.
Stainless steel, polished. Rivets on sizes 2 to 5 run in bearing bushes. Bearings greased.
Ergonomic, oil-resistant handle with large hand rest and soft component. Loss protection for the clamping screw at the end of the clamping arm.
Complete with stainless clamping screw no. 6890NI.
Also suitable for the food industry.
Stainless steel, polished. Rivets on sizes 2 to 5 run in bearing bushes. Bearings greased.
Ergonomic, oil-resistant handle with large hand rest and soft component. Loss protection for the clamping screw at the end of the clamping arm.
Complete with stainless clamping screw no. 6890NI.
Also suitable for the food industry.
- Note:
Suitable sensor query for size 3 see No. 6897S.
Additional information
Weight (g):
700g
C (mm):
41,0
E (mm):
63,0
F (mm):
27
B (mm):
113
A (mm):
10
H [mm]:
45,0
L (mm):
20,5
d1 (mm):
8,5
Size:
4
M (mm):
29,0-43,0
Ø P (mm):
57,0
N (mm):
58,0
L1 (mm):
287
K (mm):
8,00
h1 (mm):
75,0
m1 (mm):
43,0
h2 (mm):
126
I (mm):
20,0
F1* (kN):
2,00kN
F2* (kN):
3,0kN
Thrust screw:
M8x65
HW min.:
-4,0
HW max.:
24,0
α:
90°
Diameter:
8,5
