RÖHM KRF 70, 4-jaws, with clamping pin, cylindrical centering mount, cast body 148794
Sku: T-244061
€564.66 (excl. legal VAT, excl. Shipping)
In stock,ready for shipping within 48h
Piece
Product variants
| Sku: | Name: | SKU manufacturer: | ||
|---|---|---|---|---|
|
T-244059 | KRF 110, 4-jaws, with clamping pin, cylindrical centering mount, cast body | 148772 | |
|
T-244120 | KRF 125, 4-jaws, with clamping pin, cylindrical centering mount, cast body | 150758 | |
|
T-244122 | KRF 160, 4-jaws, with clamping pin, cylindrical centering mount, cast body | 150760 | |
|
T-244124 | KRF 200, 4-jaws, with clamping pin, cylindrical centering mount, cast body | 150762 |
doneType: 399-40
doneMat. Number: 148794
doneMat. Number: 148794
doneMade in Germany
RÖHM KRF 70, 4-jaws, with clamping pin, cylindrical centering mount, cast body 148794
Content:
1 Piece
Shipping:
€75.55 Paketdienst to United Kingdom
Lieferung:
Provider:
Payment methods:
Returns:
Security:
Product data
Manufacturer:
RÖHM Spanntechnik
Condition:
NEW
Sku:
T-244061
SKU manufacturer:
148794
GTIN Code (EAN):
4019208052229
Weight:
1,04 Kg
All information relating to products from RÖHM Spanntechnik. Technical and optical modifications of the manufacturer and errors reserved.
This page has been machine-translated, the original german version can be found here, please also note the Translation Disclaimer.
Product description
Crown chuck KRF, size 70, 4-jaws, with dowel pin, with drilling and turning jaws, cylindrical center mount, cast body 3- and 4-jaw chuck for positioning and transporting workpieces, e.g. on measuring machines workpiece by turning the clamping ringSizes 125 - 200: incl. 4 set screws for fine adjustment during assemblyCast bodyJaws in the chuck ground out for concentricity-6-jaw chuck for grinding twist drills available on request
Application areas:
3- and 4-jaw chuck for positioning and transporting workpieces, e.g. on measuring machines.
Customer benefits:
Simple clamping of the workpiece by turning the clamping ringSizes 125 - 200: incl. 4 set screws for fine adjustment during assemblyCast body jaws Ground in the chuck for concentricity
Technical features:
6-jaw chuck for grinding twist drills available on request
Application areas:
3- and 4-jaw chuck for positioning and transporting workpieces, e.g. on measuring machines.
Customer benefits:
Simple clamping of the workpiece by turning the clamping ringSizes 125 - 200: incl. 4 set screws for fine adjustment during assemblyCast body jaws Ground in the chuck for concentricity
Technical features:
6-jaw chuck for grinding twist drills available on request
- UB
- Particularly successful and effective when strength is the top priority. Even large dimensions and heavy weights are firmly under control - absolutely safe!
- Röhm lathe chucks are used wherever economical and precise clamping is required.DURO wedge bar chucks and face spiral chucks (DIN 6350 and DIN 6351) are used successfully where extremely high clamping forces, high concentricity and reliable long-term repeatability are required.The three-jaw DURO wedge bar chuck is characterized by very high clamping force and accuracy, which is twice as high as required in DIN 6386.The concentricity and face accuracy of the three- and four-jaw face spiral chucks corresponds to DIN 6386, Part 1, accuracy class I.In order to machine large and heavy workpieces with the highest possible cutting performance, optimal clamping with high forces is required.Röhm face plates, up to a diameter of 4500 mm, have proven themselves to be ideal for this with their undeniable advantages.In conjunction with RÖHM clamping tools The modular palletizing system POWER GRIP creates multifunctional processing options.
- AAB827c003
- KRF ring chuck, size 70, 4-jaws, with clamping pin, with drilling and turning jaws, cylindrical centering mount, cast body
- Type 399-40 KRF 4-jaw cast body
- Type: 399-40
- Note: 4-jaw ring chuck with clamping pin, with 1 set of jaws stepped outwards and inwardsCylindrical centering mount
- Tool group: A09
- * Jaws reversibleSizes 125 - 200: incl. 4 threaded pins for fine adjustment during assemblyOther sizes and mounts available on request
Additional information
Size:
70
Tensile strength:
2.5
Zoll:
2¾
Fastening thread mm:
3xM6
Mounting hole circle mm:
39
Torque (Nm):
12
Bore mm:
16
Rear rotation mm:
52
Height baking over feed body mm:
13.6
Length cheeks mm:
32
Span B mm:
2-70
Centre diameter mm:
48
Centring depth mm:
1,5
