ELMAG Hydraulic workshop press XL 81820
Sku: T-492761
€12,154.29 (excl. legal VAT, excl. Shipping)
In stock,ready for shipping within 48h
Piece
Product variants
| Sku: | Name: | SKU manufacturer: | ||
|---|---|---|---|---|
|
T-492711 | Hydraulic workshop press XL | 81823 | |
|
T-493320 | Hydraulic workshop press XL | 81822 | |
|
T-494759 | Hydraulic workshop press XL | 81821 |
doneSerie WPMEH - Pressleistung bis 300 t
donePREMIUM WPMEH 100/2 (D=1500mm)
donePREMIUM WPMEH 100/2 (D=1500mm)
Hydraulic workshop press XL PREMIUM WPMEH 100/2 (D=1500mm)|Standard features|- Overload safety valve
- Compression pressure gauge
- Up/down control valve
- Cylinder piston, chrome-plated
- Press table with locking pin
- Operating instructions/CE
- Compression pressure gauge
- Up/down control valve
- Cylinder piston, chrome-plated
- Press table with locking pin
- Operating instructions/CE
Content:
1 Piece
Shipping:
The shipping costs for United Kingdom could not be calculated automatically.
Provider:
Sales and delivery by ToolTeam®
Payment methods:
Returns:
Security:
Product data
Manufacturer:
ELMAG
Condition:
NEW
Sku:
T-492761
SKU manufacturer:
81820
GTIN Code (EAN):
9004853818202
Weight:
1145,00 Kg
All information relating to products from ELMAG. Technical and optical modifications of the manufacturer and errors reserved.
This page has been machine-translated, the original german version can be found here, please also note the Translation Disclaimer.
Product description
- Hydraulic presses with electric drive
- Powerful bending, straightening, punching and light deep-drawing work (5%)
- Perforated guide frame with locking pin for press table adjustment
- With press table chain for convenient height adjustment
- Includes 230 V socket
- Chrome-plated cylinder pistons
- Robust welded construction
- TB 125 Vario - klein ganz groß, - Überlast-Sicherheitsventil
- Pressdruckmanometer
- Schaltventil Auf/Ab
- Zylinderkolben verchromt
- Pressentisch mit Absteckbolzen
- Betriebsanleitung / CE
Additional information
Intake height max. (mm):
880mm
Intake length (mm):
1.500mm
Electro-hydraulic drive ():
Ja
Hydraulic cylinder laterally adjustable ():
Ja
Piston speed Stage 1/2 (mm/s):
7,54 / 2,47mm/s
Piston stroke (mm):
380mm
Manual hand pump ():
Ja
Machine width with pump (mm):
865mm
Machine width (mm):
755mm
Machine height (mm):
2.080mm
Machine length with pump (mm):
2.065mm
Machine length without pump (mm):
1.750mm
Engine power (kW):
2,2kW
Mains connection (V/Hz):
400/50-60V/Hz
Oil flow rate Stage 1/2 (l/min):
5,64 / 17,2l/min
Press table chain (height adjustment) ():
Ja
Pressure performance max.:
100t
Return speed (mm/s):
9.06mm/s
Bearer width (mm):
300mm
Two drive speeds ():
Ja
