AMF 6832E-2 Horizontal clamp with blue handle 557673
Sku: T-297370
€30.29 (excl. legal VAT, excl. Shipping)
In stock,ready for shipping
Piece
Product variants
| Sku: | Name: | SKU manufacturer: | ||
|---|---|---|---|---|
|
T-297368 | 6832E-0 Horizontal clamp with blue handle | 557671 | |
|
T-297369 | 6832E-1 Horizontal clamp with blue handle | 557672 | |
|
T-297371 | 6832E-3 Horizontal clamp with blue handle | 557674 | |
|
T-297372 | 6832E-4 Horizontal clamp with blue handle | 557675 | |
|
T-297373 | 6832E-5 Horizontal clamp with blue handle | 557676 |
doneWeight (g): 185g
doneC (mm): 26,0
doneC (mm): 26,0
doneE (mm): 32,0
doneF (mm): 16
doneF (mm): 16
AMF - ANDREAS MAIER GmbH & Co. KG 6832E-2 Horizontal clamp with blue handle 557673
Content:
1 Piece
Shipping:
€41.93 Versandservice to United Kingdom
plus €10.00 stock transfer surcharge
For orders under €63.03 order total plus €9.24 Surcharge
Lieferung:
Provider:
Sales and delivery by ToolTeam Köln
Payment methods:
Returns:
Security:
Product data
Manufacturer:
AMF - Andreas Maier GmbH & Co.KG Schloss- u. Werkzeugfabrik
Condition:
NEW
Sku:
T-297370
SKU manufacturer:
557673
GTIN Code (EAN):
4020772013288
Weight:
0,19 Kg
All information relating to products from AMF - Andreas Maier GmbH & Co.KG Schloss- u. Werkzeugfabrik. Technical and optical modifications of the manufacturer and errors reserved.
This page has been machine-translated, the original german version can be found here, please also note the Translation Disclaimer.
Product description
Horizontal clamp with blue handle with open holding arm and vertical base.
Galvanized and passivated. Rivets made of stainless steel, which run in case-hardened bearing bushes for sizes 2 to 5. Bearings greased.
Ergonomic, oil-resistant handle with large hand rest and soft component. Loss protection for the clamping screw at the end of the clamping arm.
Complete with tempered, galvanized clamping screw
No. 6890.
Galvanized and passivated. Rivets made of stainless steel, which run in case-hardened bearing bushes for sizes 2 to 5. Bearings greased.
Ergonomic, oil-resistant handle with large hand rest and soft component. Loss protection for the clamping screw at the end of the clamping arm.
Complete with tempered, galvanized clamping screw
No. 6890.
Additional information
Weight (g):
185g
C (mm):
26,0
E (mm):
32,0
F (mm):
16
B (mm):
64
A (mm):
6
H [mm]:
40,0
L (mm):
12,7
d1 (mm):
5,6
Size:
2
M (mm):
29,5-34,0
Ø P (mm):
38,0
N (mm):
21
L1 (mm):
164
K (mm):
6,0
h1 (mm):
61,0
m1 (mm):
34,0
h2 (mm):
68
I (mm):
13,2
F1* (kN):
1,0kN
F2* (kN):
1,2kN
Thrust screw:
M6x35
HW min.:
15,0
HW max.:
22,0
α:
90°
Diameter:
5,6
ØO:
5
