AMF 6214RM-250 clamping module, mechanical, screw-in version 559090 Thumbnail

AMF 6214RM-250 clamping module, mechanical, screw-in version 559090

Sku: T-1509999

Discontinued item

Weight (g): 26g
H [mm]: 28,2 - 31,3

Size: RM250
M (mm): M16 x 1

Product data

Manufacturer:

AMF - Andreas Maier GmbH & Co.KG Schloss- u. Werkzeugfabrik

Condition:

NEW

Sku:

T-1509999

SKU manufacturer:

559090

GTIN Code (EAN):

4020772019839

Weight:

0,03 Kg

All information relating to products from AMF - Andreas Maier GmbH & Co.KG Schloss- u. Werkzeugfabrik. Technical and optical modifications of the manufacturer and errors reserved. This page has been machine-translated, the original german version can be found here, please also note the Translation Disclaimer.

Product description

Clamping module, mechanical, screw-in version
open mechanically.
Housing and piston hardened.
Repeatability < 0.1 mm.

Additional information

Weight (g):

26g

H [mm]:

28,2 - 31,3

Size:

RM250

M (mm):

M16 x 1

R (mm):

14,75

t1 (mm):

1,95

h1 (mm):

7,6

h2 (mm):

Diameter d:

Ø D1:

Ø D2:

2,1

ODH:

10,6

Clamping force up to (N):

100N

Holding force N:

1000N

T2:

T3:

16,7

Related results

4020772019839 power clamps clamping irons clamping pads straightening and support elements clamping bolts and floating clamps clamping screws nuts and washers clamping sets and accessories pull-down clamps positioning elements stops and precision T-nuts eccentric and centering clamps AMF 559090 AMF - ANDREAS MAIER GmbH & Co. KG

Complete catalogs
