AMF 140RD-40 Lock case with roller latch lock for triangular and profile cylinders, bright 557066
Sku: T-294268
Discontinued item
doneClosure: PZ
doneWeight (g): 2550g
doneWeight (g): 2550g
doneCabinet width A (mm): 40mm
doneC (mm): 173mm
doneC (mm): 173mm
AMF - ANDREAS MAIER GmbH & Co. KG 140RD-40 lock case with roller latch lock for triangular and profile cylinders, blank 557066
Product data
Manufacturer:
AMF - Andreas Maier GmbH & Co.KG Schloss- u. Werkzeugfabrik
Condition:
NEW
Sku:
T-294268
SKU manufacturer:
557066
GTIN Code (EAN):
4020772007515
Weight:
2,55 Kg
All information relating to products from AMF - Andreas Maier GmbH & Co.KG Schloss- u. Werkzeugfabrik. Technical and optical modifications of the manufacturer and errors reserved.
This page has been machine-translated, the original german version can be found here, please also note the Translation Disclaimer.
Product description
Lock case with roller latch lock for triangular and profile cylinders, bright
with galvanized roller latch lock for triangular and profile cylinders no.RD, with stainless steel cuff. Can be used on the right and left. Prepared for triangular and profile cylinders (PZ). Without change.
- Spindle 30 and 60 mm
- Turn 1-turn
- Distance 72 mm
with galvanized roller latch lock for triangular and profile cylinders no.RD, with stainless steel cuff. Can be used on the right and left. Prepared for triangular and profile cylinders (PZ). Without change.
- Spindle 30 and 60 mm
- Turn 1-turn
- Distance 72 mm
- Application:
The practical solution for systems to which two people (groups) should have independent access: for example, fire department access roads or garbage container fences. The lock case with two cylinders allows the fire department or waste disposal companies access using a triangular socket key - and can also be integrated into the normal locking system. After the bolt has been closed, the gate can simply be pushed open using the roller latch (fixed fittings recommended).
Note:
The cylinders can be operated independently of one another and open or close the bolt. Installation of triangular and profile cylinders without jamming the lock is possible regardless of the locking bit position when the triangular socket key is removed.
The following arrangement of triangular and profile cylinders must be observed:
- Spindle 30 mm: profile cylinder
- Spindle 60 mm: triangular cylinder
Additional information
Closure:
PZ
Weight (g):
2550g
Cabinet width A (mm):
40mm
C (mm):
173mm
E (mm):
33mm
F (mm):
34,5mm
B (mm):
94mm
H [mm]:
34,0mm
