AMF 140RD-30 Lock case with roller latch lock for triangular and profile cylinders, bright 557063
Sku: T-294267
Discontinued item
Product variants
| Sku: | Name: | SKU manufacturer: | ||
|---|---|---|---|---|
|
T-294270 | 142RD-40 roller latch lock for triangular and profile cylinders, galvanized | 557072 |
doneClosure: PZ
doneWeight (g): 1470g
doneWeight (g): 1470g
doneCabinet width A (mm): 30mm
doneC (mm): 172mm
doneC (mm): 172mm
AMF - ANDREAS MAIER GmbH & Co. KG 140RD-30 lock case with roller latch lock for triangular and profile cylinders, blank 557063
Product data
Manufacturer:
AMF - Andreas Maier GmbH & Co.KG Schloss- u. Werkzeugfabrik
Condition:
NEW
Sku:
T-294267
SKU manufacturer:
557063
GTIN Code (EAN):
4020772007508
Weight:
1,47 Kg
All information relating to products from AMF - Andreas Maier GmbH & Co.KG Schloss- u. Werkzeugfabrik. Technical and optical modifications of the manufacturer and errors reserved.
This page has been machine-translated, the original german version can be found here, please also note the Translation Disclaimer.
Product description
Lock case with roller latch lock for triangular and profile cylinders, bright
with galvanized roller latch lock for triangular and profile cylinders no.RD, with stainless steel cuff. Can be used on the right and left. Prepared for triangular and profile cylinders (PZ). Without change.
- Spindle 30 and 60 mm
- Turn 1-turn
- Distance 72 mm
with galvanized roller latch lock for triangular and profile cylinders no.RD, with stainless steel cuff. Can be used on the right and left. Prepared for triangular and profile cylinders (PZ). Without change.
- Spindle 30 and 60 mm
- Turn 1-turn
- Distance 72 mm
- Application:
The practical solution for systems to which two people (groups) should have independent access: for example, fire department access roads or garbage container fences. The lock case with two cylinders allows the fire department or waste disposal companies access using a triangular socket key - and can also be integrated into the normal locking system. After the bolt has been closed, the gate can simply be pushed open using the roller latch (fixed fittings recommended).
Note:
The cylinders can be operated independently of one another and open or close the bolt. Installation of triangular and profile cylinders without jamming the lock is possible regardless of the locking bit position when the triangular socket key is removed.
The following arrangement of triangular and profile cylinders must be observed:
- Spindle 30 mm: profile cylinder
- Spindle 60 mm: triangular cylinder
Additional information
Closure:
PZ
Weight (g):
1470g
Cabinet width A (mm):
30mm
C (mm):
172mm
E (mm):
24mm
F (mm):
33,5mm
B (mm):
94mm
H [mm]:
33,5mm
